Project Proposal, System Layout & Shading Analysis

Free With System Purchase — Get a Quote

RESIDENTIAL PRELIMINARY STANDARD DESIGN LAYOUT

Solar Power System Analysis and Design Layout.

This report consists of minimum of four pages, containing a System Summary with the following information:

• Maximum PV System Size
• Estimated power production (Based on PV Watts)
• Financial & Cash Flow Analysis (if requested)
• Installation Area (Length and Width)
• Roof Slope and Azimuth
• Layout of the house with solar modules placed on the most beneficial roof angles, taking into consideration obstructions such as: attic vents, exhaust pipes, chimneys, etc.
• Up to three free revisions.

Download Standard System Layout Example
