Modules starting at $0.84 per watt.
| Mechanical Properties | |
|---|---|
| Cells | 6 x 10 |
| Cell vendor | LG |
| Cell type | Monocrystalline / N-type |
| Cell dimensions | 156.75 x 156.75 mm / 6 inches |
| # of busbar | 12 (Multi Wire Busbar) |
| Dimensions (L x W x H) | 1640 x 1000 x 40 mm 64.57 x 39.37 x 1.57 inch |
| Front Load | 6000 Pa / 125 psf |
| Rear Load | 5400 Pa / 113 psf |
| Weight | 17.0 ± 0.5 kg / 37.48 ± 1.1 lbs |
| Connector type | MC4, MC4 Compatible, IP67 |
| Junction box | IP 67 with 3 bypass diodes |
| Length of cables | 2 x 1000 mm / 2 x 39.37 in |
| Glass | High transmission tempered glass |
| Frame | Anodized aluminum |
| Certifications and Warranty | |
| Certifications (In Progress) | IEC 61215, IEC 61730-1/-2, UL 1703, ISO 9001, IEC 62716 (Ammonia Test), IEC 61701(Salt Mist Corrosion Test) |
| Product warranty | 12 years |
| Module Fire Performance (USA) | Type 2 (UL1703) |
| Fire Rating (for CANADA) | Class C (ULC/ORD C1703) |
| Output warranty of Pmax | 1) 1st year: 98%, 2) After 2nd year: 0.6%p annual degradation, 3) 83.6% for 25 years Linear warranty* |
| Temperature Characteristics | |
| NOCT | 46 ± 3 °C |
| Pmpp | -0.38 %/°C |
| Voc | -0.28 %/°C |
| Isc | 0.03 %/°C |
| Electrical Properties (STC*) | |
| MPP voltage (Vmpp) | 33.2 |
| MPP current (Impp) | 9.50 |
| Open circuit voltage (Voc) | 40.6 |
| Short circuit current (Isc) | 10.02 |
| Module efficiency (%) | 19.2 |
| Operating temperature (°C) | -40 ~ +90 |
| Maximum system voltage (V) | 1000 |
| Maximum series fuse rating (A) | 20 |
| Power tolerance (%) | 0 ~ +3 |
| Electrical Properties (NOCT*) | |
| Maximum power(Pmax) | 230 |
| MPP voltage (Vmpp) | 30.4 |
| MPP current (Impp) | 7.58 |
| Open circuit voltage (Voc) | 37.6 |
| Short circuit current (Isc) | 8.08 |
Enhanced Performance Warranty
LG NeON™2 has an enhanced performance warranty. The annual degradation has fallen from -0.7%/yr to -0.6%/yr. Even after 25 years, the cell guarantees 2.4%p more output than the previous LG NeON™ modules.
High Power Output
Compared with previous models, the LG NeON™ 2 has been designed to significantly enhance its output efficiency, thereby making it efficient even in limited space.
Aesthetic Roof
LG NeON™ 2 has been designed with aesthetics in mind; thinner wires that appear all black at a distance. The product may help increase the value of a property with its modern design.
Outstanding Durability
With its newly reinforced frame design, LG has extended the warranty of the LG NeON™ 2 for an additional 2 years. Additionally, LG NeON™ 2 can endure a front load up to 6000 Pa, and a rear load up to 5400 Pa.
Better Performance on a Sunny Day
LG NeON™ 2 now performs better on sunny days thanks to its improved temperature coefficiency.
Double-Sided Cell Structure
The rear of the cell used in LG NeON™2 will contribute to generation, just like the front; the light beam reflected from the rear of the module is reabsorbed to generate a great amount of additional power.
| Style | Black Backsheet, White Backsheet |
|---|
